Flat Collar Mc

Collar Jacquard Machine

Detail
Dearton Industrial Co., Ltd, our company is a part of a large diversified group having its operations in Taiwan & ASIA, we are one of the top designing & manufacturing of circular knitting machine in Taiwan since 1991.




Quality First & Upgrade Clients Profits First,  our spirit.
Over 30 years rich manufacturing experience , we use Japan CNC facilities to produce the knitting parts, such as: Sinker Cam Box, Cam Box, Cylinder, Carriage Ring, Yarn Carriage.


              *** All our machines with EUROPE-CE  certification !***



Mode No.: SKS-747
Name: Collar Jacquard Flat knitting machine.

SKS-747S.
Semi Jacquard + Bird Eyes function
                  40”, 1 head, 1x1 system
                   52”, 1 head, 1x1 system
                   80",  2 head, 2x1 system

 SKS-747J.  Fully Jacquard + Bird Eyes function
                  40”, 1 head, 1x1 system
                   52”, 1 head, 1x1 system
                   80",  2 head, 2x1 system
# SKS-747 Collar Fully Jacquard Flat knitting machine
















Specification ( SKS-747 )
Application: COLLAR  Carriage/knitting system: 1/1 ; 2/1
Computerized: Fully Jacquard Video Technical Support: on line
Condition: 100% New Gauge: 12g , 14 g, 16g, 18g.
Brand: SKS, HiroSaki Width: 40"/ 52” /60"/80"/96"/100"
Power: 1.0 KW Machinery Test report: Provided
Weight: 1500 kg Video outgoing-inspection: Provided
Dimension: 2580*850*1870mm Warranty of core components: 1 Year
Racker: Motor , max transverse 2” Needle Electronic Actuator: 8
Voltage: AC220/50Hz Wooden case Packing: Provided
Packing: 4 sets per 20' container ( 52" x 4 sets = 20'GP )
                4 sets per 40' container (80"  x 4 sets = 40'GP )
