SKS-RB2, Rib High Speed Machine

#SKS-RB2 is a RIB circular knitting machine is a type of double jersey circular knitting machine that is specifically designed to produce rib knit fabrics, such as 1x1, 2x2, 3x3 ribs, and other elastic double-knit structures.

Machine Type: Double jersey circular knitting machine
Needle Arrangement: Two sets of needles—cylinder and dial—arranged alternately to produce rib structures
Gauge Range: Typically from 8G to 20G, depending on desired fabric fineness
Diameter Options: Commonly between 9" to 36"
Feeder Count: 2.0F/feeder
Yarn Types: Compatible with cotton, polyester, spandex blends, and other fibers
Versatility: Capable of producing various rib structures such as 1x1, 2x2, and 3x3 by adjusting needle arrangements
Elasticity: Produces fabrics with excellent width-wise stretch and recovery, ideal for cuffs, collars, and waistbands
Fabric Stability: Rib fabrics lie flat without curling, providing a stable base for garments
Production Efficiency: High-speed operation with options for computerized control enhances productivity

What Rib fabric that #SKS-RB2 can knit ?
1x1 Rib Knit Fabric/ Approximately 180–200 GSM.
Description: Alternating knit and purl stitches every other stitch, creating a highly elastic fabric,
Applications: Commonly used for neckbands, cuffs, and waistbands

2x2 Rib Knit Fabric/ Approximately 200–220 GSM
Description: Two knit stitches followed by two purl stitches, offering a balanced appearance with moderate elasticity
Applications: Suitable for sweaters, scarves, and beanies

3x3 Rib Knit Fabric / Approximately 260 GSM
Description: Three knit stitches followed by three purl stitches, resulting in a wider rib pattern with less elasticity
Applications: Ideal for fashion garments requiring a textured appearance

Rib Knit with Spandex Blend
Description: Incorporates spandex fibers for enhanced stretch and recovery.
Applications: Used in activewear, leggings, and fitted garments

Priority of #SKS-RB2

Professional Statements to Emphasize Strength and Durability
Technical & Engineering Focus. Engineered with a reinforced frame and premium-grade materials to ensure maximum structural integrity and long-term reliability under high-speed operation."

Built to withstand continuous, heavy-duty production environments with minimal maintenance requirements."

Features hardened cam systems and precision-machined components for exceptional wear resistance and mechanical stability.
Equipped with a robust needle bed and vibration-absorbing base for superior machine life and fabric consistency.
Marketing & Business-Friendly Phrasing
Our rib machine delivers unmatched durability, ensuring years of high-performance knitting without compromise."
Designed for continuous production with minimal downtime — strong, stable, and built to last."
Trusted by top textile mills for its rugged construction and dependable output.
An investment in quality — crafted for durability performance.
Cast iron or steel frame
High-speed bearing systems
Wear-resistant cams and sinkers
Automatic lubrication system

3. GSM (Grams per Square Meter)
1x1 Rib 180 – 240 GSM Cuffs, neckbands, lightweight tops
2x2 Rib 200 – 260 GSM Waistbands, tight-fitted tops
3x3 Rib 220 – 300 GSM Sweaters, structured garments

5. Cam Setting

1x1 Knit = Empty, Knit... Purl, Empty, Purl...

= Every alternate needle on both beds

2x2 Knit, Knit, Empty, Empty... Purl, Purl, Empty, Empty...

= Two needles active, two off (both beds)

3x3 Knit ×3, Empty ×3... Purl ×3, Empty ×3...

= Three needles active, three off

SKS-DJ6/ Double Jersey circular Knitting machine
Inch: 9 - 32"
Gauge: 7g - 20g
Feeder: 2.0F

#SKS-DJ6 / PILOT RUN BEFORE SHIP.

Our enterprise is a part of a large diversified group and we have our
factories in Taiwan and China for the Design and production of the
High-Quality-Circular Knitting Machine. We have a group of professional
Technicians and we have vertically integrated design, and manufacturing
capabilities for high-quality circular knitting Machines! We have been
providing brands with the highest quality guarantee, our company has
continued to successfully act as a silent and competent technical
manufacturer for many years.

Core Value
1. We have 35 years of production experience from Taiwan since 1987.
we have Japan CNC facilities to produce the knitting parts, such as:
Sinker Cam Box, Cam Box, Cylinder, Carriage Ring, Yarn Carriage.
All our circular knitting machines with solid Strong quality with high speed.

2. Our Machinery is being rewarded with CE & ISO-9001 Certification.

3. Our circular knitting machine innovation upgrades with German knitting
machine technical synchronization, inheritance of Taiwan knitting spirit
to the pursuit of knitting technological innovation to assure worldwide
knitting mills use our circular knitting machine.

All our machines are CE-certified, fully compliant with EU standards. Our products are widely recognized in global markets for their superior performance, durability, and innovation.
