Winding Benefits
Improves yarn feeding stability
Proper winding tension ensures smooth and continuous yarn feeding on knitting and weaving machines, reducing stoppages and defects.
Prevents yarn breakage and fuzz
Balanced tightening and loosening control avoids over-tight winding, minimizing yarn stress, hairiness, and breakage during processing.
Ensures uniform cone shape and density
Even package build-up allows consistent unwinding speed, which is critical for high-speed knitting and dyeing operations.
Enhances dyeing uniformity
Well-formed cones with stable density enable even dye penetration, reducing shade variation and re-dye risk.
Increases production efficiency
Stable winding reduces machine downtime caused by yarn tangling or collapse, improving overall productivity.
Reduces waste and rework
Automatic stop on yarn break and controlled winding help minimize yarn loss and the need for rewinding.
Suitable for multiple yarn types
Adjustable tension makes the machine flexible for different yarn counts and materials used in knitting and dyeing preparation.
.jpg)
.png)
SKS-75. Thread/Yarn Winder ( before dyeing )
Application:
1. SKS-75 High speed thread winding machine is applicable for winding Cotton
yarn, sewing thread, embroidery thread, nylon thread ,etc.
2. This machine features availability of computer-based separate control of each
single spindle, a frequency –change slotted spool yarn guide device, an electro-magnetic
tension force control system, a pump-based cycling –type oiling device ,…etc !
3. Characteristics of a good shape formation , high efficiency , easy operation , assured
safety and reliability and broad applicability , and so on.
4/ Best of all, each machine has 4 Mitsubishi inverter protection devices.
Computer yarn-length measurement.
1. Yarn length measured by computer, accuracy +1%.
2. Advanced touch panel, adjustable yarn winding speed, 400-1000m/min, can set winding
length, winding quantity, tanker speed, etc., can be displayed in advanced touch panel.
3. Each spindle is equipped with electronic tension, which can be adjusted on the
touch screen, and a manual tensioner.
4.Yarn pattern can be manually adjusted.
5. Non-contact light rod detector, stop yarn breaking automatically.
6. Each machine is equipped with independent oil drum, automatic oil circulation,
7. 30 years of machinery manufacturing, high efficiency, high quality, easy to operate!
.jpg)
Automatic lubrications system.
1. Threads are being uniform lubricate, thanks to the constant yarn speed, the oiling roller speed is adjustable.
2. Release the tension from beginning to the end; it makes the winded package good appearances
3. LED display easy operation.
.jpg)
Circulating oil device.
1. Keep always the full level of oil to each spindle.
2. Big-scale return oil trough and oil fender to filter without pollution and oil waste.
3. One oil filter is devoiced for every oil wheel to reduce the oil slinging out.
4. Each machine has its own oil tank
5. Detachable filter, easy to clean.
Configured brand
- Inverter: Mitsubishi/ JAPAN
- Motor: huangjie(more than 20 years of cooperation)
- Bearing: NSK/ JAPAN
