Main Features:
- Accurate yarn doubling ensures consistent yarn count and improved strength independent tension control for each yarn end, guaranteeing uniform twisting and smooth running.
- High-speed operation with low vibration for stable, continuous production
- Automatic stop motion when yarn breaks, reducing waste and operator intervention
- Uniform package build suitable for knitting, weaving, and dyeing processes
- Wide yarn range compatibility, including cotton, polyester, nylon, acrylic, and blended yarns
- User-friendly operation with easy tension adjustment and low maintenance design
Benefits:
- Improves yarn strength and appearance
- Enhances fabric quality and machine efficiency downstream
- Reduces yarn defects and production loss
| Type | A | B | ||
| Gauge | 336 | 420 | 420 | 520 |
| Piles | 2-3 | 2-3 | 2-3 | 2-4 |
| Traverse | 152 | 215 | 152/215 | 250 |
| Spindle No. | 12 | 10 | 10 | 8 |
| Yarn | short fiber/short fiber with spandex | |||
| Length | 152/215mm | 250mm | ||
| Section No. | ≤12 | |||
| Yarn Count | 10Ne-80Ne short fiber 10Ne-80Ne | |||
| RPM | ≤800r/min | |||
| Bobbin Size | 170mm/230mm | 280mm/290mm | ||
| Cone kg | ≤3KG | ≤5KG | ||
| Spindle | 120 | 96 | ||
| Dimension | 2100*1550*1400mm | 2100*1650*1550mm | ||
| Cabinet | 400 × 600 × 1100 mm | |||
| Optional |
|
|||
